Dell OptiPlex 3070 with i5-9600k on macOS Monterey 12.2
Bootloader version: Opencore 0.7.7 macOS version: macOS Monterey 12.2 (21D49)
Hardware Specification
Working:
CPU Turbo Boost & Thermal Throttling Audio GPU All USB Ports LAN Airdrop & Airplay Sleep Internal sound and hdmi
Not working:
Display sleep (thinks it's an external monitor)
BIOS Settings
General → Advanced Boot Options: uncheck System Configuration → SATA Operation: AHCI Secure Boot → Secure Boot Enable: Disabled Intel® Software Guard Extensions™ → Intel® SGX™ Enable: Disabled Power Management → Block Sleep: check Virtualization Support → VT for Direct I/O: uncheck
BIOS Settings via GRUB (Optional)
Set Pre-Allocated DVMT to 64M: setup_var 0x8DC 0x02 Disable CFG lock: setup_var 0x5BE 0x00
DELL_OptiPlex_3070_OC_v7.7
Bootloader version: Opencore 0.7.7 macOS version: macOS Monterey 12.2 (21D49)
Hardware Specification
| Component | Specs |
|---|---|
| CPU | Intel® Core™ i5-9600k |
| RAM | 8gb DDR4 2400MHZ |
| HDD | Samsung EVO 970 NVMe SSD 256GB |
| iGPU | Intel® UHD Graphics 630 |
| Audio | RRealtek ALC3234 |
| OS | macOS Monterey 12.2 (21D49) |
| Boot | OpenCore 0.7.7 |
Working:
CPU Turbo Boost & Thermal Throttling Audio GPU All USB Ports LAN Airdrop & Airplay Sleep Internal sound and hdmi
Not working:
Display sleep (thinks it's an external monitor)
BIOS Settings
General → Advanced Boot Options: uncheck System Configuration → SATA Operation: AHCI Secure Boot → Secure Boot Enable: Disabled Intel® Software Guard Extensions™ → Intel® SGX™ Enable: Disabled Power Management → Block Sleep: check Virtualization Support → VT for Direct I/O: uncheck
BIOS Settings via GRUB (Optional)
Set Pre-Allocated DVMT to 64M: setup_var 0x8DC 0x02 Disable CFG lock: setup_var 0x5BE 0x00
DELL_OptiPlex_3070_OC_v7.7
- Laptop Modeli
- Asus R752L
- Anakart Modeli
- ASUS X751LA Intel Lynx Point-LP (Premium)
- İşlemci Modeli
- Intel Core i3-5010U 2 x 2.1 GHz, Broadwell
- Grafik Kartı
- Intel HD Graphics 5500, NVIDIA GeForce 920M
- Ses Kartı Modeli
- Realtek High Definition Audio
- Ağ Aygıtları
- Atheros AR9485
- Disk ve RAM
- Samsung MZ-76E500B/EU 860 EVO 500
